Overview:
SKY04L is a Lite version (i.e. LCOS model) of SKY04 series.
By adjusting the focus, 1280*960 high resolution LCOS screen, colorful screen, pilots can see more details in racing.
With the Steadyview receiver, the receiver combines two signals, avoiding image tearing and rolling, resulting in more stable and clearer images in challenging conditions.
The newly designed lens features focus adjustment and 39 degree field of view, giving pilots a more realistic FPV experience.
New operating system with 10 languages to choose from, pilots have no problem with the menu system with the shuttle wheel and a new user interface, pilots can do all the settings just by turning the wheel without removing their glasses.
Specifications:
Brand Name: Skyzone
Product Name: SKY04L
White
Screen: LCOS
Resolution: 1280X960
FOV (diagonal): 39°
Aspect Ratio: 4:3/16:9
Focus: -6~+6 adjustable
Interpupillary Distance (IPD): 58-71 ((
Receiver: 5.8Ghz 48CH Steadyview Receiver
Language: 10 languages
Power supply: DC 6.5-25.2V / USB 5V
Power Consumption: 720mA at 12V
DVR: H264, 30fps, MOV 6Mbps, SD Card support up to 128Gb
Head Tracker: 3-axis accelerometer, 3-axis gyroscope
Size: 185*75*67mm
Weight: 267g
feature:
- steadyview 5.8G 48CH receiver
- Focus adjustment -6 ~ + 6
- FOV 39 °
- LCOS 1280*960 high resolution screen
- Dual module bay
- Bullet head with fogging fan and cooler
- IPD range 58〜71 mm
- Channel Scan
- Type C connector to upgrade firmware or electric glasses.
- HDMI in
- Support 2S-6S wide voltage.
- Build in Headtracker
- H.264 DVR, SD card support up to 128GB
English Manual, click here
Included in the list:
1x SKY04L Glasses
1x Steadyview Receiver Module
2x Faceplate (wide and narrow)
1x sponge
1x zipper
1x power cable
1x Headtracker cable
2x 5.8GHz 2dB antennas
1x video/audio cable
1x USB-C cable
1x Uer manual
