Sensor Type Sony 1/3" CMOS
SensorScale4:3/16:9
SwitchableTv SystemPAL/NTSC SwitchableResolution1000TVLShutter
SpeedPAL 1/25~1/10000 sec;
NTSC 1/30~1/10000 sec
Video OutputCVBS Analog SignalFOV
1.8mm: FOV-H:115° FOV-D: 150°
2.5mm: FOV-H:105° FOV-D: 130°
Shutter SpeedAutoMinimum Illumination0.01LuxWhite
Working Temperature-10°~50°C RH90% MAXWorking
Humidity20~80%Storage Temperature-20°~70°C
Consumption50mA±15% @
DC12V 115mA±15% @ DC5V
Dimension22*22mm; 28*22mm Add Bracket
Weight12g(Exclude cable)
