Summary
DoMain is GEPRC’s new generation of consumer Freestyle FPV drone, It brings pilots the GEPRC team’s comprehensive technical evolution, as well as a deep comprehension of the Freestyle quadcopters , DoMain is made for the dream Freestyle FPV drone what we’ve been looking for.
Feature
- Unique structure design,Increase the stability of the frame structure.
- The new side panel design is integrated, supporting DIY side panel decals.Higher creativity and diversity.
- Equipped with sufficient power, it can complete difficult freestyle flight.
- Support full-size GOPRO or naked GOPRO on itself, Shooting all perfect footages in the view
- DC structure design, the frame looks neat and compact.The extraordinary high integration, Without Prop in the view, showing you a pure picture.
- Equipped with M-10 GPS to ensure the safety of every flight with rescue mode.
Specifications
- Product name: 3.6 DoMain FPV
- Frame:GEP-DoMain Frame
- Wheelbase:170mm
- Roof thickness:2mm
- Base plate thickness: 2.5mm
- Arm thickness:4.0mm
- Midplate thickness:3mm
- FC:TAKER F722 SE
- ESC:TAKER E55A 32Bit 4IN1
- MCU: STM32F722RET6
- Gyro: MPU6000
- OSD:AT7456E
- VTX:GEPRC/GEPRC RAD MINI 1W VTX
- Camera:Runcam phoenix2p
- Antenna:Momoda-MMCX90-R-BR-100MM black background with red words, elbow, right-hand rotation
- Motor:SPEEDX2 2105.5 2650KV( M5 Shift)
- Propellers: GEMFAN 3630 – 3
- Weight: 279g ±5g
- Receiver:PNP/ TBS NanoRX / GEPRC ELRS2.4
- Recommend battery:Lipo 6S 1050-1300mah
- Connector:XT60
Includes
1 x DoMain
2 x GEMFAN 3630-3(1 pair)
2 x M15*200mm Battery cable tie
1 x Spare screw bag
1 x L-shaped screwdriver(1.5mm)
1 x L-shaped screwdriver (2mm)
1 x M8 Wrench
1x Left and right side panels
