Description
Our new XING 2005 motor was specially designed for ultra-light or toothpick 5 inch rigs around 250g. XING technology inside for ultra smooth and powerful flight experience. Available in 2550KV (4S) or 1900KV (6S) which can be coupled with our new Nazgul 5030 props or any other 1.5mm shaft prop on the market.
Features
3mm inner shaft, 1.5mm outer titanium alloy shaft
Japanese NSK φ8*φ3*4 bearings
N52H curved magnets
Motor wires protected
Dynamically balanced
Specifications
KV: 1900KV / 2550KV
Weight(included wire): 21g
Dimension: φ26.8*19mm
Interphase Resistance: 125.3mΩ / 130.8mΩ
Input Volts: 24V / 16V
Peak Current: 19.37A / 24.41A
Max Watt: 464.9W / 390.6W
Mounting Holes: 12*12 φ2mm
Rotor Specifications: Unibell
Shaft Diameter: 1.5mm
Shaft Protruding Length: 5mm
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ8*φ3*4
Winding: Single Strand copper winding
Packing List
1x XING 2005 Motor
4x M2*6 screws
4x M2*7 screws
